Male to Male Jumper Wires – single

BC557 is a widely used PNP bipolar junction transistor manufactured in small TO-92 package. It is a general purpose PNP transistor that can be used as a switch or amplifier in electronic circuits. Its HFE ratings are 125 to 800 which makes it an ideal transistor to use as a small signal amplifier in electronic circuits for example for audio signal amplification or other, the HFE ratings of BC557 can be determined by the last letter after its number for example BC557A HFE ratings are 110-220, BC557B HFE ratings are 200-450 and BC557C HFE ratings are 420-800. The max collector dissipation is 500 milliwatt which is also an another good point to use it in amplification stages. Moreover it will also perform well when used it as a switch for load under 100mA. The transistor has also good collector to emitter (VCE) value that is -45V, therefore you can easily use it in circuits using 40 to 45 volts DC.

BC327 is a general purpose PNP BJP transistor that can be used for switching and amplification purposes in electronic circuits. The transistor features 800mA collector current hence it can be used to drive variety of loads in an electronic application. The max collector-emitter voltage is -45V therefore it can easily handle load voltage under 45V. Apart from that transistor also features 625mW collector dissipation and DC current gain of maximum 630 therefore it can also be used as an audio amplifier or for any type of signal amplification.
