7476 Dual Master-Slave J-K Flip-Flop
Original price was: ₹90.00.₹61.50Current price is: ₹61.50. + GST
- Supply Voltage : 7V
- Input Voltage : 5.5V
- Operating Free Air Temperature Range : 0C to +70C
- Storage Temperature Range : 65C to +150C
25 in stock
7476 IC contains two independent positive pulse triggered J-K flip-flops with complementary outputs.
The J and K data is processed by the flip-flop after a complete clock pulse. While the clock is LOW the slave is isolated from the master. On the positive transition of the clock, the data from the J and K inputs is transferred to the master. While the clock is HIGH the J and K inputs are disabled. On the negative transition of the clock, the data from the master is transferred to the slave. The logic state of J and K inputs must not be allowed to change while the clock is HIGH. The data is transferred to the outputs on the falling edge of the clock pulse. A LOW logic level on the preset or clear inputs will set or reset the outputs regardless of the logic levels of the other inputs.
1 review for 7476 Dual Master-Slave J-K Flip-Flop
You must be logged in to post a review.
