₹15.00Original price was: ₹15.00.₹6.72Current price is: ₹6.72. + GST
This is a 8MHZ Crystal. This is a low cost crystal oscillator with?oscillation frequency of 8Mhz. Crystal are normally required to provide?clock pulses to your micro controller or other IC’s which require external clock?source.
An oscillator crystal has two electrically conductive plates, with a slice or?tuning fork of quartz crystal sandwiched between them. The crystal oscillator?circuit sustains oscillation by taking a voltage signal from the quartz?resonator, amplifying it, and feeding it back to the resonator. Quartz has the?further advantage that its elastic constants and its size change in such a way?that the frequency dependence on temperature can be very low.
₹15.00Original price was: ₹15.00.₹6.72Current price is: ₹6.72. + GST
Crystal Oscillators are used as a quick and easy way to offer circuits a very accurate and consistent frequency output. This 16 MHz Crystal is a thru-hole type and is typically used with microcontrollers.
₹150.00Original price was: ₹150.00.₹110.00Current price is: ₹110.00. + GST
1-Channel?Solid-State Relay is some what similar to that of a mechanical relay & the difference is that, there is no moving contact in a Solid-State Relay. Here we make use of Phototropic coupler to turn it ON and OFF.
₹312.00Original price was: ₹312.00.₹246.16Current price is: ₹246.16. + GST
Specification
This relay module is 5 Volts active low.
It is an 8-channel relay interface board, which can be controlled directly by a wide range of microcontrollers such as Arduino, AVR, PIC, ARM, PLC, etc.
It is also able to control various appliances and other equipments with large current.
Relay output maximum contact is AC250V 10A and DC30V 10A.
Standard interface can be directly connected with microcontrollers.
Red working status indicator lights are conducive to the safe use.
Widely used for all MCU control, industrial sector, PLC control, smart home control.
Input port IN1, IN2, IN3, IN4, IN5, IN6, IN7, IN8 low signal level effectively.
VCC, GND : Input power.
JD – VCC : Relay power input port,relay can power alone.
Working voltage : 5V
Module weight : about 112g
package weight : about 150g
module size : about 1.7cm X 5.5cm X 13.7cm(height * width * long)
