⚠️ The Problem :

In smart grid and distributed energy systems, reverse current flow can damage sensitive electronics, disrupt communication modules, or even trip the entire grid segment. This typically happens when power from solar inverters, batteries, or backup systems flows backward into unintended paths.

✅ The Solution :

The easiest and most efficient way to fix this is by using MOSFET-based reverse protection circuits. Unlike diodes, which waste power through voltage drops, P-channel or N-channel MOSFETs can act as ideal diodes, offering low resistance and minimal loss.

🧰 Practical Example :

Let’s say you’re working on a solar-powered energy monitor for a smart grid testbed. During a battery swap, reverse polarity occurs and the whole board fries. By adding a reverse protection MOSFET, you protect all downstream components, ensuring reliable operation even during faults.

📐 Sample Calculation :

If your system runs on 12V and draws 2A:

Power loss with diode = 0.7V × 2A = 1.4W

Using a MOSFET with 30mΩ Rds(on):

Loss = I²R = (2)² × 0.03 = 0.12W

That’s over 10× more efficient!
