🛑 The Problem: Reverse Polarity Can Kill Your Sensors

Sensors are often delicate and can be damaged instantly if power is connected in reverse. This is a common issue in prototyping and DIY projects, especially when testing quickly with jumper wires or breadboards. One accidental swap of VCC and GND, and your sensor may never recover.

🔧 The Solution: Simple Reverse Polarity Protection

You can protect your sensor using a Schottky diode or a P-channel MOSFET in series with the VCC line. A Schottky diode drops less voltage and is easy to implement, while a P-MOSFET offers almost no voltage drop and higher efficiency—ideal for battery-powered or low-voltage systems.

🧪 Practical Example

Let’s say you’re using an ultrasonic sensor powered by 5V. If you add a 1N5819 Schottky diode in series with the VCC line, the diode will block current if power is reversed. Your sensor stays safe!

📐 Sample Calculation

Say your sensor draws 100mA, and the diode has a forward voltage of 0.4V:

Power loss = P=V×I=0.4V×0.1A=40mW— acceptable for most applications.
