Category: IC and Chips
IC and Chips
Showing 33–48 of 69 results
-
KB688 -120V, -8A Transistor PNP
Original price was: ₹70.00.₹41.50Current price is: ₹41.50. + GSTAdd to cartSpecification Type Designator: 2SB688. Material of Transistor: Si. Polarity: PNP. Maximum Collector Power Dissipation (Pc): 80 W. Maximum Collector-Base Voltage |Vcb|: 120 V. Maximum Collector-Emitter Voltage |Vce|: 120 V. Maximum Emitter-Base Voltage |Veb|: 5 V. Maximum Collector Current |Ic max|: 8 A. Max. Operating Junction Temperature (Tj): 150 ?C. Transition Frequency (ft): 5 MHz. Collector …
-
L7905CV IC – 5V Negative Voltage Regulator IC
Original price was: ₹15.00.₹8.20Current price is: ₹8.20. + GSTAdd to cartThe LM7905 series of three terminal negative regulators are available in TO- IC Data Sheetnd with several fixed output voltages, making them useful in a wide range of applications. Each type employs internal current limiting, thermal shut down and safe operating area protection, making it essentially indestructible. Perfect for use in various electronics projects in India, LM7905 IC – 5V Negative Voltage Regulator IC ensures reliability and performance. Ideal for various electronics projects, LM7905 IC – 5V Negative Voltage Regulator IC offers quality and performance.
-
LM317 ic Adjustable Voltage Regulator
Original price was: ₹15.00.₹9.05Current price is: ₹9.05. + GSTRead moreThey are exceptionally easy to use and require only two external resistors to set the output voltage. Further, both line and load regulation are better than standard fixed regulators. Also, the LM317 is packaged in standard transistor packages which are easily mounted and handled. In addition to higher performance than fixed regulators, the LM317 series offers full overload protection available only in ICs. Included on the chip are current limit, thermal overload protection and safe area protection. Perfect for use in various electronics projects in India, LM317 ic Adjustable Voltage Regulator ensures reliability and performance. Ideal for various electronics projects, LM317 ic Adjustable Voltage Regulator offers quality and performance.
-
LM324 Low Power Quad Op-Amp IC DIP
Original price was: ₹11.00.₹7.54Current price is: ₹7.54. + GSTAdd to cartFeatures of LM324 Op-Amp
- Internally frequency compensated for unity gain.
- Large DC voltage gain :100dB.
- Wide operating supply range (Vcc=3V~32V).
- Input common-mode voltage includes ground.
- Large output voltage swing: From 0V to Vcc-1.5V.
- Power drain suitable for battery operation.
Perfect for use in various electronics projects in India, LM324 Low Power Quad Op-Amp IC DIP ensures reliability and performance. Ideal for various electronics projects, LM324 Low Power Quad Op-Amp IC DIP offers quality and performance.
-
LM386N Audio Power Amplifier
Original price was: ₹20.00.₹11.48Current price is: ₹11.48. + GST -
LM3914 Dot/Bar Display Driver IC DIP-18 Package
Original price was: ₹78.00.₹22.10Current price is: ₹22.10. + GSTRead moreThe LM3914 is a monolithic integrated circuit that senses analog voltage levels and drives 10 LEDs, providing a linear analog display. A single pin changes the display from a moving dot to a bar graph. Current drive to the LEDs is regulated and programmable, eliminating the need for resistors. This feature is one that allows operation of the whole system from less than 3V.
The circuit contains its own adjustable reference and accurate 10-step voltage divider. The low-bias-current input buffer accepts signals down to ground, or V, yet needs no protection against inputs of 35V above or below ground. The buffer drives 10 individual comparators referenced to the precision divider. Indication non-linearity can thus be held typically to %, even over a wide temperature range.
Versatility was designed into the LM3914 so that controller, visual alarm, and expanded scale functions are easily added on to the display system. The circuit can drive LEDs of many colors, or low-current incandescent lamps. Many LM3914s can be chained to form displays of 20 to over 100 segments. Both ends of the voltage divider are externally available so that 2 drivers can be made into a zero-center meter.
The LM3914 is very easy to apply as an analog meter circuit. A 1.2V full-scale meter requires only 1 resistor and a single 3V to 15V supply in addition to the 10 display LEDs. If the 1 resistor is a pot, it becomes the LED brightness control. The simplified block diagram illustrates this extremely simple external circuitry.
When in the dot mode, there is a small amount of overlap or fade (about 1 mV) between segments. This assures that at no time will all LEDs be OFF, and thus any ambiguous display is avoided. Various novel displays are possible.
Much of the display flexibility derives from the fact that all outputs are individual, DC regulated currents. Various effects can be achieved by modulating these currents. The individual outputs can drive a transistor as well as a LED at the same time, so controller functions including staging control can be performed. The LM3914 can also act as a programmer, or sequencer.
The LM3914 is rated for operation from 0C to +70C. The LM3914N-1 is available in an 18-lead PDIP (NFK) package. Perfect for use in various electronics projects in India, LM3914 Dot/Bar Display Driver IC DIP-18 Package ensures reliability and performance. Ideal for various electronics projects, LM3914 Dot/Bar Display Driver IC DIP-18 Package offers quality and performance.
-
LM3915 LED Dot/Bar Display Driver IC DIP-18 Package
Original price was: ₹40.00.₹28.93Current price is: ₹28.93. + GSTAdd to cartSpecification:-
Parameter Value Power Dissipation (3) PDIP (NFK) 1365 mW 1365 mW Supply Voltage 25V Voltage on Output Drivers 25V Input Signal Overvoltage +-35V Divider Voltage -100mV to V+ Reference Load Current 10 mA Storage Temperature Range -55?C to 150?C Lead Temperature (Soldering, 10 sec.) 260?C ?
-
LM7806 IC – 6V Positive Voltage Regulator | TO-220 Package
Original price was: ₹10.00.₹5.00Current price is: ₹5.00. + GSTAdd to cartEnsure stable 6V output with the LM7806 IC. Features internal current limiting, thermal shutdown, and a robust TO-220 package for reliable power regulation.
-
LNK305PN IC – Power Integrations – AC-DC Off Line Switcher IC
Original price was: ₹82.00.₹62.34Current price is: ₹62.34. + GSTAdd to cartSpecification:-
Symbol Parameter Min Type Max Units VBP BYPASS Pin Voltage 5.55 5.8 6.10 V VBPH BYPASS Pin Voltage Hysteresis 0.8 0.95 1.2 V tON(MIN) Minimum On Time 280 360 475 ns tLEB Leading Edge Blanking Time 170 215 ns TSD Thermal Shutdown Temperature 135 142 150 ?C TSHD Thermal Shutdown Hysteresis 75 ?C -
MAX232 – RS232 to TTL Converter 3V, 5V Compatible IC
Original price was: ₹28.00.₹18.08Current price is: ₹18.08. + GSTAdd to cartMAX232 is a communication IC. It is used to convert TTL Signals to RS232 Signal and vice versa.?MAX232?provides RS-232 voltage level outputs (approx. ? 7.5 V) from a single + 5 V supply via on-chip charge pumps and external capacitors. This makes it useful for implementing RS-232 in devices that otherwise do not need any voltages outside the 0 V to + 5 V range, as power supply design does not need to be made more complicated just for driving the RS-232 in this case.
-
MIC29302 – (SMD TO-263 Package) – LDO Voltage Regulator
Original price was: ₹100.00.₹87.00Current price is: ₹87.00. + GSTAdd to cartnan Perfect for use in various electronics projects in India, MIC29302 – (SMD TO-263 Package) – LDO Voltage Regulator ensures reliability and performance. Ideal for various electronics projects, MIC29302 – (SMD TO-263 Package) – LDO Voltage Regulator offers quality and performance.
-
MOC3021 IC Optocoupler Traic Driver IC
Original price was: ₹20.00.₹14.76Current price is: ₹14.76. + GSTAdd to cartThe MOC3021 is an optically Isolated Triac Driver Device, contains a GaAs infrared emitting diode and a light activated silicon bilateral switch, which functions like a triac. This device is designed for interfacing between electronic controls and power triacs to control resistive and inductive loads for 115VAC operations. Perfect for use in various electronics projects in India, MOC3021 IC Optocoupler Traic Driver IC ensures reliability and performance. Ideal for various electronics projects, MOC3021 IC ? Optocoupler Traic Driver IC offers quality and performance.
-
MOC3063 IC – Zero-Cross Triac Opto Isolator IC
Original price was: ₹30.00.₹20.55Current price is: ₹20.55. + GSTAdd to cartThe MOC3063 devices consist of gallium arsenide infrared emitting diodes optically coupled to monolithic silicon detectors performing the functions of Zero Voltage Crossing bilateral triac drivers. They are designed for use with a triac in the interface of logic systems to equipment powered from 115/240 Vac lines, such as solid?state relays, industrial controls, motors, solenoids and consumer appliances,etc.
-
NCP1200P60 Switching Controllers 60KHz Current Mode
Original price was: ₹50.00.₹35.22Current price is: ₹35.22. + GSTAdd to cartNCP1200 PWM Current-Mode Controller for Low-Power Universal Off-Line Supplies Housed in SOIC?8 or PDIP?8 package, the NCP1200 represents a major leap to ward ultra?compact Switch mode Power Supplies. Due to a novel concept, the circuit allows the implementation of acomplete offline battery charger or a standby SMPS with few external components
-
NE-555 Timer IC
Original price was: ₹15.00.₹3.25Current price is: ₹3.25. + GSTAdd to cartexternal resistors and one capacitor. The circuit may be triggered and reset on falling waveforms, and the output circuit can source or sink up to 200 mA or drive TTL circuits. Features of LM555 : Direct replacement for SE555/NE555 Timing from microseconds through hours Operates in both astable and monostable modes Adjustable duty cycle Output …
-
NE5532P IC
Original price was: ₹30.00.₹24.70Current price is: ₹24.70. + GSTAdd to cartFeatures:-
• Equivalent Input Noise Voltage:
• 5 nV/√Hz Typ at 1 kHz
• Unity-Gain Bandwidth: 10 MHz Typ
• Common-Mode Rejection Ratio: 100 dB Typ
• High DC Voltage Gain: 100 V/mV Typ
• Peak-to-Peak Output Voltage Swing 26 V Typ With VCC± = ±15 V and RL = 600 Ω
• High Slew Rate: 9 V/μs Typ
