Mastering MOSFET High-Frequency Switching

MOSFET high-frequency switching

When building power converters, LED drivers, or motor controllers, high-frequency switching with MOSFETs is essential. But many hobbyists face excess heat or efficiency loss when switching above 50kHz. The problem? Improper MOSFET selection or gate drive setup.




🔧 The Problem :



At high frequencies, gate charge (Qg) becomes critical. If you use a standard MOSFET without considering its Qg or gate drive current, switching losses dominate and cause heating or reduced efficiency.




💡 The Solution :



Pick a low Qg MOSFET with fast switching characteristics, and pair it with a suitable gate driver IC that can source and sink enough current quickly—ideally >1A for frequencies above 100kHz.




🧪 Practical Example :



If you’re building a 100kHz boost converter for an LED strip, and your MOSFET has a Qg of 40nC, to switch efficiently:

Required gate current (I) = Qg × f = 40nC × 100kHz = 4mA

But add margins: use a gate driver capable of at least 100mA to 500mA.
