LM3914 Dot/Bar Display Driver IC DIP-18 Package
Original price was: ₹78.00.₹22.10Current price is: ₹22.10. + GST
The LM3914 is a monolithic integrated circuit that senses analog voltage levels and drives 10 LEDs, providing a linear analog display. A single pin changes the display from a moving dot to a bar graph. Current drive to the LEDs is regulated and programmable, eliminating the need for resistors. This feature is one that allows operation of the whole system from less than 3V.
The circuit contains its own adjustable reference and accurate 10-step voltage divider. The low-bias-current input buffer accepts signals down to ground, or V, yet needs no protection against inputs of 35V above or below ground. The buffer drives 10 individual comparators referenced to the precision divider. Indication non-linearity can thus be held typically to %, even over a wide temperature range.
Versatility was designed into the LM3914 so that controller, visual alarm, and expanded scale functions are easily added on to the display system. The circuit can drive LEDs of many colors, or low-current incandescent lamps. Many LM3914s can be chained to form displays of 20 to over 100 segments. Both ends of the voltage divider are externally available so that 2 drivers can be made into a zero-center meter.
The LM3914 is very easy to apply as an analog meter circuit. A 1.2V full-scale meter requires only 1 resistor and a single 3V to 15V supply in addition to the 10 display LEDs. If the 1 resistor is a pot, it becomes the LED brightness control. The simplified block diagram illustrates this extremely simple external circuitry.
When in the dot mode, there is a small amount of overlap or fade (about 1 mV) between segments. This assures that at no time will all LEDs be OFF, and thus any ambiguous display is avoided. Various novel displays are possible.
Much of the display flexibility derives from the fact that all outputs are individual, DC regulated currents. Various effects can be achieved by modulating these currents. The individual outputs can drive a transistor as well as a LED at the same time, so controller functions including staging control can be performed. The LM3914 can also act as a programmer, or sequencer.
The LM3914 is rated for operation from 0C to +70C. The LM3914N-1 is available in an 18-lead PDIP (NFK) package. Perfect for use in various electronics projects in India, LM3914 Dot/Bar Display Driver IC DIP-18 Package ensures reliability and performance. Ideal for various electronics projects, LM3914 Dot/Bar Display Driver IC DIP-18 Package offers quality and performance.
Sold out!
Specification:-
| Parameter | Value |
| Part number | LM3914 |
| Channels | 10 |
| Vin (Min) (V) | 3 |
| Vin (Max) (V) | 15 |
| Vout (Min) (V) | 1.2 |
| Vout (Max) (V) | 1.34 |
| Type | Dot/Bar Display Driver |
| LED current per channel (mA) | 10 |
| LED (#) | 10 |
| Shutdown current (Typ) (uA) | 2.4 |
| Features | Internal voltage reference, Programmable output current |
| Operating temperature range (C) | 0 to 70 |
| Package Group | DIP |
| No of Pins | 18 |
Key Applications: Used widely in electronic circuits, automation, robotics, and educational projects. Optimized for reliable performance in India-specific environments and conditions.
Keywords: LM3914 Dot/Bar Display Driver IC DIP-18 Package, electronic components India, LM3914 Dot/Bar Display Driver IC DIP-18 Package buy online, electronic supplies India, LM3914 Dot/Bar Display Driver IC DIP-18 Package price.
Applications: Suitable for electronics projects, automation, and educational purposes. Widely used in Indian and international markets.
Keywords: LM3914 Dot/Bar Display Driver IC DIP-18 Package, buy LM3914 Dot/Bar Display Driver IC DIP-18 Package online, electronics components, LM3914 Dot/Bar Display Driver IC DIP-18 Package features, LM3914 Dot/Bar Display Driver IC DIP-18 Package applications, high quality LM3914 Dot/Bar Display Driver IC DIP-18 Package
