The Problem :

When working with chargers, one common issue is reverse current flow—when power flows backward through the circuit. This can cause damage to sensitive components like diodes, transistors, or even your charger itself. In simple terms, it’s like trying to push water through a pipe the wrong way—it just doesn’t work and can lead to serious damage.

The Solution :

To fix this, engineers use reverse current protection. One of the most common methods is using a diode or a MOSFET in the right direction to block current from flowing backward. In a practical scenario, if you connect a battery charger in reverse, it could send current in the opposite direction, potentially ruining your equipment. By adding a diode in series with the charger, you ensure that any reverse current is blocked, protecting your components.

Simple Example :

Imagine you’re building a battery charger for a solar panel. If the charger’s connections are reversed, reverse current could flow back to the panel, potentially damaging it. By placing a diode in the charging circuit, you can prevent this from happening, ensuring the current only flows in the right direction.

Sample Calculation :

Let’s say you need a diode with a forward voltage drop of 0.7V.

If your charger is providing 5V and the battery requires 4.2V, the diode ensures that the excess voltage doesn’t reach the battery in reverse.

Product Suggestion :

Want to get started? Try using a MOSFET or diode for reverse current protection in your projects. Shop now at SmartXProKits for high-quality Made in India components.

Support our work and India’s innovation—buy from our Make in India site!
