The Problem: Overheating MOSFETs
MOSFETs are essential in power electronics, but if they get too hot, they can fail silently or catastrophically. The root cause is thermal impedance—how well the MOSFET dissipates heat from its junction to the environment. Without proper heat management, even a low R<sub>DS(on)</sub> MOSFET can reach dangerous temperatures during high current loads.
The Solution: Managing Thermal Impedance
To fix this, always design with thermal resistance in mind. Here’s how:
Use MOSFETs with low R<sub>θJA</sub> or R<sub>θJC</sub>.
Add a heatsink or thermal pad to pull heat away efficiently.
Apply thermal paste to improve surface contact.
Optimize PCB copper area for better dissipation.
These steps help keep your components cool and your circuit reliable.
Practical Example: A DIY Motor Controller
You’re using an IRF540N to control a 12V DC motor. The current draw is 10A. Without a heatsink or paste, your MOSFET could quickly overheat—even if it’s technically “within spec.”
Sample Calculation: Temperature Rise
Let’s do the math:
P = I² × R = 10² × 0.05 = 5W
With R<sub>θJA</sub> = 62°C/W (no heatsink):
Temp rise = 5 × 62 = 310°C
Add a heatsink with 10°C/W:
New rise = 5 × 10 = 50°C
Now your MOSFET stays safe under load.
Product Suggestion: Made in India Solutions
Protect your project with quality MOSFETs and thermal paste—tested and Made in India!
Shop now at SmartXProKits.in
Support our work and India’s innovation—buy from our Make in India site!
Written by smartxbrains
