When building electronics circuits, one common issue that can cause damage is reversed polarity—where the positive and negative wires are accidentally swapped. This simple mistake can fry components, leading to costly repairs. Luckily, it’s easy to protect your circuits using a BJT (Bipolar Junction Transistor).
The Problem :
Reverse polarity happens when the power supply’s positive and negative terminals are connected incorrectly. This can cause electrical components, like ICs or LEDs, to burn out. The good news is that with a BJT, you can easily safeguard your circuit.
A simple way to prevent damage is to add a BJT switch in series with your power input. If the polarity is correct, the BJT will allow the current to pass through. If the polarity is reversed, the BJT will block the current, thus protecting the components downstream.
Practical Example :
Imagine you’re powering a small circuit with a 9V battery. If you accidentally reverse the battery’s connections, a regular circuit could be damaged. However, by adding a BJT in the power line, you ensure that, even with reversed polarity, the circuit remains safe.
Simple Calculation :
If using a 9V supply and a BJT with a current gain (hFE) of 100, and you’re drawing 50mA, the base current required will be:
I_b = I_c / hFE = 50mA / 100 = 0.5mA.
This small current is enough to activate the BJT and protect your circuit!
Shop Now !
For your next project, get quality BJTs and other Made in India components at Shop Now at SmartXProKits.in. These products are designed for hobbyists, engineers, and prototypers just like you.
Support our work and India’s innovation—buy from our Make in India site!
Written by smartxbrains
