When working with HVAC systems, one common issue that can occur is reverse polarity. This happens when the power supply’s positive and negative connections are swapped. It can cause serious damage to the system and components. The good news? It’s easy to fix with the right protection.

The Problem :

 In simple terms, reverse polarity occurs when electricity flows in the wrong direction. In HVAC systems, this can lead to components like relays, sensors, and circuit boards being damaged or malfunctioning. The solution is simple: reverse polarity protection using diodes or MOSFETs. These components ensure that current flows only in the correct direction, safeguarding your system.

Practical Example :

Imagine you’re building a prototype HVAC controller. You connect the power supply but accidentally reverse the polarity. Without protection, the components could burn out. By adding a diode or MOSFET at the input, the current will only flow in the right direction, preventing damage even if the connections are reversed.

Sample Calculation :

Let’s say you use a 5V power supply and a 1N4007 diode for protection.

The voltage drop across the diode is about 0.7V, so the output voltage to the system will be 4.3V (5V – 0.7V).

For most low-power systems, this small voltage drop won’t affect performance.
