As an electronics hobbyist or engineer, you may have faced the issue of low voltage with your ESP32 boards, causing instability or unexpected resets. The ESP32 is a powerful microcontroller used in many projects, but it requires a stable 3.3V to 5V power supply for optimal performance. If the voltage drops below this range, your board may malfunction.

The Problem :

A common scenario occurs when you’re powering the ESP32 through a USB or external battery, and the voltage drops due to a weak power source. This can cause the ESP32 to reset or fail to boot entirely. It’s like trying to run a device on low battery—it just won’t work properly.

The Solution :

To fix this, use a voltage regulator to ensure your ESP32 always receives a stable voltage. For example, a 5V USB charger can supply inconsistent voltage, so using a 5V to 3.3V regulator is a simple solution. This keeps the voltage stable even when power sources fluctuate.

Sample Calculation :

Suppose you’re using a 5V source to power your ESP32.

You need to drop it to a steady 3.3V. If your ESP32 draws 100mA, the power consumed can be calculated by:

P=V×I=3.3V×0.1A=0.33W

Make sure your voltage regulator can handle the required power without overheating.

Component Suggestion :
